M12 M16 Gridded Fixture Plate Modular Clamping Plate Subplate Grid Holes

Name: M12 M16 Gridded Fixture Plate Modular Clamping Plate Subplate Grid Holes
Brand: ADJIG
Price: 560 USD

Brand Name : ADJIG

Model Number : BP05

Place of Origin : Chongqing, China

MOQ : 5

Payment Terms : L/C,T/T

Supply Ability : Less than 20 pieces, shipped within 10 days. More than 20 items will be shipped within 15-20 days.

Delivery Time : 7-10 days

Packaging Details : Carton/Wooden crate

Price : 560-1410 USD per item

Material : FC30

Heat Treatment : Burnished

Contact Now

Gridded Fixture Plate Modular Clamping Plate Subplate Grid Holes for Flexible Workholding Systems

Base Plate
Material: FC30
Heat Treatment: Burnished
Application: Suitable for horizontal MC
Features: Utilizes hole-based positioning with standardized fixture components for rapid assembly
A set of fixtures meeting requirements

Model No.	A	B	C	D	T		H	P	S	MTP	Mountingholes	KG
BP05-50400-0400-12	50	400	320	55	Ø12	M12	50	7	7	59	4	54
BP05-50500-0500-12	50	500	400	75	Ø12	M12	50	9	9	93	8	83
BP05-50630-0630-12	50	630	500	100	Ø12	M12	50	11	11	139	8	135
BP05-50800-0800-12	50	800	640	135	Ø12	M12	50	15	15	237	8	206
BP05-50400-0400-16	50	400	320	55	Ø16	M16	50	7	7	59	4	52
BP05-50500-0500-16	50	500	400	75	Ø16	M16	50	9	9	93	8	80
BP05-50630-0630-16	50	630	500	100	Ø16	M16	50	11	11	139	8	130
BP05-50800-0800-16	50	800	640	135	Ø16	M16	50	15	15	237	8	204
